Product detailed description
GPON OLT V1600GS-O32 – Single PON Solution with Built-in 1×32 Splitter
The V1600GS-O32 from VSOL is a 1U GPON OLT with one PON port and an integrated 1×32 optical splitter. Designed for cost-effective FTTH networks, it provides high throughput, up to 20 km reach, and flexible uplinks.
✅ Main Advantages
- Built-in 1×32 splitter reduces ODN cost
- Downstream rate 2.488 Gbps, upstream 1.244 Gbps
- Transmission distance up to 20 km
- Uplink: 2× GE RJ45 + 1× SFP/SFP+ 10GE
- Supports AC and DC power supply
- Management via Web, CLI, Telnet, Console
📊 Technical Specifications
| Parameter |
Value |
| PON Ports |
1× GPON (integrated 1×32 splitter) |
| Uplink Ports |
2× GE RJ45 + 1× SFP/SFP+ 10GE |
| Downstream Rate |
2.488 Gbps |
| Upstream Rate |
1.244 Gbps |
| Max Distance |
20 km |
| Fiber Type / Connector |
9/125 µm SM, SC/UPC |
| Backplane Bandwidth |
60 Gbps |
| Forwarding Rate |
21.6 Mpps |
| Dimensions |
442 × 173 × 43.5 mm |
| Weight |
2.41 kg |
| Power Supply |
AC 100-240 V / DC 12 V (optional) |
| Power Consumption |
≈12 W |
| Operating Temperature |
−20 °C to +60 °C |
| Storage Temperature |
−40 °C to +70 °C |
| Humidity |
5–95 % non-condensing |
🛡️ Advanced Features
- Compliant with ITU-T G.984.x GPON standard
- VLAN, QoS, ACL, IGMP Snooping
- ONT auto-discovery and remote firmware upgrade
- Surge protection: 4 kV power, 1 kV interfaces
✅ Ideal Use Cases
- Small FTTH deployments with up to 32 subscribers
- SOHO and small offices
- Community or municipal networks
- Upgrade of legacy single-PON OLTs
